CP-EUT-6TP2
CAT 6 UTP LAN Cable
- Conforms to TIA /EIA- 568-C.2
- Excellent Margin with suppression of Cross Talk (NEXT)
- 2 conductors twisted together to form a pair
- 20 Mtr. Standard Cable Length
- 4 Pairs are laid up and separated from one another through a Cross Separator
- Laid up of 4 Pairs is sheathed with PVC
| onduct Type | Stranded Bare Electrolytic Grade Copper |
| Nominal Conductor Diameter | 24AWG (7/0.195 ± 0.010) |
| Insulation | Polyethylene (HDPE) |
| No. of Pair | 4, Each pair Twisted |
| Pairing | Twisted into Two core |
| Connector Type | UTP RJ-45 3Part Connector both ends |
| Outer Sheath Material | PVC |
| Colour of Sheath | Grey |
| Approximate OD | 5.90mm ± 0.20mm |
| Cable Skew | Max. 45 (ns/100 Mtr.) |
| Conductor Resistance | Max. 98 @20°C |
| Standard Length | 20 Mtr. |
| Temperature Rating | -15°C to +70°C |
| Resistance Unbalance | 5 Max |
| Capacitance Unbalance | Max. 330 (pf/100 Mtr.) |
| Velocity of Propagation | 69% |
| Mutual Capacitance | Max. 5.6 (nf/100 Mtr.) |
